2-Phase Open Loop Stepper Motor Series 86AM85

Original price was: ₹6,000.00.Current price is: ₹5,100.00.

  1. Step angle :- 1.8 Degree
  2. Holding Torque :- 8.5 Nm
  3. Rated Current :- 6 A
  4. Resistance/phase :- 0.53 Ohm
  5. Inductance/phase :- 5.54 mH
  6. Rotor Inertia :- 2800 g-cm^2
  7. Shaft dia :- 14 mm
  8. Shaft length :- 32 mm
  9. Length :- 112 mm
  10. Weight :- 3.67 kg
1 in stock
Add to Wishlist
Add to Wishlist
Category:

Description

The stepper motor is a special motor specially designed for accurate control of position and speed. The biggest characteristic of stepper motor is “digital”. For each pulse signal from the controller, the stepper motor driven by its drive runs at a fixed angle. Rtelligent A/AM series stepper motor is designed based on the Cz optimized magnetic circuit and adopts stator and rotator materials of high magnetic density, featuring a high energy efficiency.
